OK thanks for posting a new question. It keeps the threads clean and clear.
My first suggestion is to try this branch:
https://github.com/DinoChiesa/Apigee-Java-WsSec-Signature-2/tree/remove-str-transform
This branch removes a bit of code that registers a Java Security Provider to handle STR Transforms in the signature. An STR in this case is a Security Token Reference. What Is a Security Token Reference?
from https://www.w3.org/2008/xmlsec/Drafts/transform-note/Overview-diff.html#WSS-STR-Transform
The STR Transform [WSS_STRTransform] is a way to sign tokens that are not part of the message. or, are part of the message, but are referred indirectly.
In the first case, Suppose a signature is signed with a X509 certificate, and the KeyInfo contains only the IssuerSerial of the certificate. If the signature includes a Reference to the KeyInfo, it is only signing the IssueSerial of the certificate, not the actual certificate. This is where an STR-Transform comes in - it is a transform that "resolves" token references and replaces them with actual tokens, i.e. it will replace the IssuerSerial with the actual certificate. So if this signature contains an STR-Transform, it will sign the actual certificate even though the actual certificate is not in the message.
In the second case, indirect reference, there is a ds:Reference that points to a SecurityTokenReference, which itself points to a SAML Assertion, which is in the XML document. Just WHY a signer would want to sign this way, with two hops, is a little unclear to me. Why not have the ds:Reference point directly to the SAML Assertion, which is an XML element in the document after all? But anyway, thank you, over-enthusiastic XML spec writers of the mid-2000's, that's possible in XML DSIG and WSSE. And in fact, the only examples I have that use STR-Transform show this scenario.
STR-Transform can be viewed as a combination of two transforms, because it
- at first replaces token references by actual tokens in the nodeset
- then canonicalizes this nodeset with the replaced references
it looks like this in the signed WS-Security document:
<wsse:Security xmlns:wsu="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-wssecurity-utility-1.0.xsd"
xmlns:wsse="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-wssecurity-secext-1.0.xsd"
SOAP-ENV:mustUnderstand="1">
<!-- The actual security token -->
<wsse:BinarySecurityToken EncodingType="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-soap-message-security-1.0#Base64Binary" ValueType="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-x509-token-profile-1.0#X509v3" wsu:Id="X509-ABCD">****</wsse:BinarySecurityToken>
<ds:Signature xmlns:ds="http://www.w3.org/2000/09/xmldsig#" Id="SIG-206">
<ds:SignedInfo>
<ds:CanonicalizationMethod Algorithm="http://www.w3.org/2001/10/xml-exc-c14n#">
<ec:InclusiveNamespaces xmlns:ec="http://www.w3.org/2001/10/xml-exc-c14n#" PrefixList="SOAP-ENV"/>
</ds:CanonicalizationMethod>
<ds:SignatureMethod Algorithm="http://www.w3.org/2000/09/xmldsig#rsa-sha1"/>
<ds:Reference URI="#id-205">
<ds:Transforms>
<ds:Transform Algorithm="http://www.w3.org/2001/10/xml-exc-c14n#">
<ec:InclusiveNamespaces
xmlns:ec="http://www.w3.org/2001/10/xml-exc-c14n#" PrefixList=""/>
</ds:Transform>
</ds:Transforms>
<ds:DigestMethod Algorithm="http://www.w3.org/2000/09/xmldsig#sha1"/>
<ds:DigestValue>***</ds:DigestValue>
</ds:Reference>
<ds:Reference URI="#STR-XYZ">
<ds:Transforms>
<!-- The STR Transform -->
<ds:Transform Algorithm="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-soap-message-security-1.0#STR-Transform">
<wsse:TransformationParameters>
<ds:CanonicalizationMethod Algorithm="http://www.w3.org/2001/10/xml-exc-c14n#"/>
</wsse:TransformationParameters>
</ds:Transform>
</ds:Transforms>
<ds:DigestMethod Algorithm="http://www.w3.org/2000/09/xmldsig#sha1"/>
<ds:DigestValue>****</ds:DigestValue>
</ds:Reference>
</ds:SignedInfo>
<ds:SignatureValue>****</ds:SignatureValue>
<ds:KeyInfo Id="KI-ABCXYZ">
<!-- The Security Token REFERENCE -->
<!-- This could just as easily be the actual Security Token! -->
<wsse:SecurityTokenReference wsu:Id="STR-XYZ">
<wsse:Reference URI="#X509-ABCD" ValueType="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-x509-token-profile-1.0#X509v3"/>
</wsse:SecurityTokenReference>
</ds:KeyInfo>
</ds:Signature>
Correctly validating a signature that uses an STR-Transform requires that the validator (in this case, this Java callout) has access to the original cert, to de-reference it when validating the signature.
The one set of examples I have that use STR-Transform, apply them to SAML Assertions. As a result, the STR are not external. They are included in the XML document.
In the main branch, there is code that registers a Security Provider, specifically so it can handle the STR-Transforms. But that code isn't a general solution. It does not "resolve an external token". It is able only to resolve to a token that is present in the XML document. It's not able to fulfill an "extra hop" reference to a Security Token , by, for example, looking in an Apigee TrustStore.
This means ... the STR-Transform code that is present in the main branch is not very useful. There doesn't seem to be a need to create a signed document this way. Putting the Security Token in one place vs another, but in the same XML document. But anyway it's possible. Some oddball generators of WS-Security do it this way. I don't know why they would. The spec allows it.
As of Saturday, 4 January 2025, 05:52, I learned that 1-14-0-apigee-3 was rejecting the use of the the code I have in the main branch, which registers the Security provider to allow the callout to perform this less-than-generally-useful STR-Transform. There are some new permission restrictions that the engineering team added to Apigee, which caused this.
The avoidance here is to use the other branch, as I stated at the top.
If that does not work for you, Unfortunately I don't have further suggestions, other than: contact Apigee support.
Good luck!
